Description
Wagner PEM-X1 Spray Gun
Manufacturer: Wagner
Part Number: 2322587
Description: Wagner PEM-X1 Spray Gun
PEM-X1
- Extremely quick and efficient color change
- Simple handling and perfect ergonomics
- Time-saving color change in 15 seconds
- Compact and always ready-to-use
- System for perfect results
- Gun-integrated dosing system
- User friendly
- Designed as a mobile system
- Continuous powder flow for best results
- Ideal ergonomics for ease of work
- Lightweight with only 490 g
- Integrated remote control for quick adjustment of the powder amount
- New nozzle concept with a sliding ring for perfect adjustable powder spray pattern
- Easy operation
- Optimal powder supply
- Finest spray with minimal air consumption
OUTPUT VOLTAGE 100,0 kVAIR INLET PRESSURE 0,3 MPa, 3,0 bar, 44 PSIOPERATING TEMPERATURE 5 – 45 °C, 41.0 – 113.0 °FWEIGHT 0,5 kg, 1.1 lb
| Parts and Accessories: |
| Ref. No. | Part No. | Description |
| 1 | – | Handle & Cable Assembly (Included in PEM-X1 Retrofit Kit) |
| 2 | 2324123 | Powder Tube |
| 3 | 2334276 | Trigger |
| 4 | 2332540 | Gun Housing |
| 5 | – | Gun Cable (Included in PEM-X1 Retrofit Kit) |
| 6 | 2322761 | Gun Hose Connection (D10-D12) |
| 7 | 2334341 | O-ring set, PEM-X1 ET |
| 8 | 2334316 | Screw Set |
| 9 | 2321978 | Hose Nipple |
| 10 | 2320464 | Union Nut |
| 11 | See Table Below | Flat Spray Nozzle |
| 12 | See Table Below | Electrode Holder |
| 13 | 2320488 | Powder Wedge |
| 14 | 2324205 | Wedge Replacement Tool |
| 15 | 2320330 | Gun Hook |
| 16 | 2324136 | Negative Cascade |
| 17 | 2322493 | Electrode Holder (Round Spray) w/ Cone Set |
| 2389365 | PEM-X1 Retrofit Kit (6m Cable) | |
| 2398699 | PEM-X1 Retrofit Kit (15m Cable) |
| Part No. | Description | |
| 2321976 | Flat jet nozzle, X1, complete |  |
| 2321981 | Deflector cone, D18, complete |  |
| 2321980 | Deflector cone, D25, complete | |
| 2321171 | Deflector cone, D34, complete | |
| 2322529 | Electrode holder, X1 F ET (Flat) |  |
| 2322490 | Electrode holder, X1 R ET (Round) |  |
| 2387104 | Set of flat jet nozzles, X1 F5 |  |
| 2390036 | Flat jet nozzle, X1 F5-X |  |
| 2322761 | Hose take-up, D10-D12, complete |  |
| 2322768 | Hose take-up, D8-D10, complete | |
| 2322868 | CoronaStar, PEM-X1, complete |  |
| 2324124 | Wedge tool, X1 + 20 wedges |  |
Nozzle Extensions:
| Part No. | Description |
| 2323366 | Nozzle extension, X1 VL 150 (150 mm; 5.91 inches) |
| 2323356 | Nozzle extension, X1 VL 300 (300 mm; 11.81 inches) |
| 2323338 | Nozzle extension, X1 VL 500 (500 mm; 19.68 inches) |
| 2324147 | Flat jet nozzle, X1 VL EXT |
| 2324148 | Round jet nozzle, X1 VL EXT |
Additional Accessories:
- 2331976 – Spare Parts Starter Pkg. X1 Ext.
- 2322493 – Wagner Round Spray Nozzle Retrofit Package
- 2324123 – Wagner PEM-X1 SP Powder Tube
- 2334341 – Wagner PEM-X1 SP O-Ring Set
- 2423223 – Non-Return Valve Assembly
