Wagner GA4000AC-IC AirCoat Automatic Air-Assisted Airless Spray Gun with Cefla Adapter Kit

Description

AirCoat Automatic Spray Gun – A level Above the “GOLD” standard in Finishing!

Manufacturer: Wagner

Part Number: GA4000ACIC-xxxxx

Description: AirCoat automatic guns with internal controller for the installation in automated lacquer spraying systems. Various base plates allow numerous installation options. With or without circulation.

Complete Gun with Base Includes:

• 2312132 Gun
• 2312144 Baseplate
• 2308808 AirCap (Red)
• 379xxx Flat Tip
• 2310534 Lock Pin (Required for Non-Circulation Systems)
• 9998993 Straight Threaded Fitting (Air) x 2
• 2314079 Cefla Adaptor

Air Cap Types: Blue High Viscosity, Red Low Volume (Shown in Pictures), or Round Spray

Reasons you should buy this gun over any other Airmix or Air Assisted Airless (AAA) on the market:

1. Highest Transfer Efficiency for Air Assisted Airless guns!  Testing has shown this gun to have a higher TE at sites and independent test results have shown this to have the highest non-electrostatic TE vs other manual guns in class.
2. Aircoat Tips are reversible for easy purging. Tips are less than other name brands!
3. No wearing O-rings and seals under the air-cap!  No expensive tip seals and o-rings to constantly maintain. The hardened plastic seals last and are $6.00 Ea or $9.00 Ea to replace. Making the cost to maintain this gun very inexpensive.

GA4000ACIC Specifications:
Fluid Inlet: I – G 1/4“
Compressed Air Connection: 8 mm
Max. Material Pressure: 250,0 bar, 3626 PSI
Max. Material Temperature: 80 °C, 176.0 °F
Max. Air Inlet Pressure: 8 bar, 116 PSI
Operating Temperature Range: 5 – 40 °C, 41 – 104 °F
Ambient Temperature: 5 – 40 °C, 41 – 104 °F
Weight: 0,7 kg, 1.5 lb
Max. Sound Level: 82 dB(A)
Length: 129,0 mm, 5.1 in
Width: 47 mm, 1.9 in
Height: 60 mm, 2.4 in

OPERATING MANUAL

BROCHURE

Accessory & Replacement Part List:

• Wagner Seal tip 394338
• Wagner Nozzle Gasket 394339
• GA4x00 Air Assist Tip 379xxx
• GA4x00 PLUS Air Assist Tip 321xxx
• GA4x00 Round Spray Tip 1327xx
• Wagner GA4000AC IC Service Kit 2314353
• Wagner GA4000AC IC Service Kit (Base Plate) 2314355
• Wagner LV Plus Red Air Cap for GA4000AC Gun 2308808
• Wagner HV Plus BLUE Air Cap for GA4000AC Gun 2308809
• Wagner Round Spray Air Cap for GA4000AC Gun 394180
• Wagner Nozzle Extension AC 300 349090
• Wagner Nozzle Extension AC 600 349091
• Wagner Straight Inline Filter DN6-PN270-G1/4-SST 2324558
