Tsunami Core Desiccant Air Dryer

Description

Tsunami Core Series Desiccant Air Dryer System with Pre-Filtration -25 CFM

Manufacturer:  Tsunami

Part Number: 21999-1225, 21999-1235

Description:

The all-new Tsunami CORE Series Desiccant Air Dryer provides world-class air dryness at an affordable price, designed solely for intermittent, lower-pressure point-of-use applications.

The Tsunami manual change desiccant cartridge eliminates dusting and tunneling of airflow through the media, improving the output air performance. The CORE dryer is designed as a complete package and includes inline pre-filtration to remove bulk liquids and fine particulates prior to drying.

• Tsunami pre-filtration includes the water separator and oil coalescing filter to remove liquid water, bulk oils, and particulate

• The Core manual change desiccant cartridge provides easy maintenance, extends media life, and eliminates dusting and tunneling

• CORE Series Dryer Systems are efficiently designed and constructed with very few moving parts, reducing potential stress points

Core Series Dryer Features

• 2-stage Pre-filtration; Water Separator, Oil Coalescing Filter
• Cartridge style desiccant for easy maintenance
• Proprietary desiccant media blend in spring loaded cartridge eliminates dusting and “tunneling”
• Automatic drains
• Wall mounting brackets
• Outlet regulator
• Machined aluminum housing & heads
• Anodized inside & out

Core Series Dryer Benefits

• Dryer Performance
• Extended Life: dryer cartridge provides 20-25% longer life than competitor brands
• First Stage Water Separator
• Removes  liquid water
• Filters particulate down to 10 microns
• Seconded Stage Oil Coalescing Filter
• Filters particulates down to .01 microns
• Removes humidity, dew points down to -80°F

Item #	21999-1225	21999-1235
Description	Air Dryer System with Pre-Filtration – 25CFM	Air Dryer System without Pre-Filtration – 25CFM
Port Size (NPT)	1/2 Inlet/Outlet	1/2 Inlet/Outlet
Drain	Float	Float
Max PSI	200	200
Max °F	175°	175°
Weight	25 lbs	14 lbs
Dimensions (in)	22 x 13 x 7	22 x 5 x 7

Site Navigation –

Spare Parts –

Item #	Description
21999-1230	Desiccant cartridge replacement
21999-1146	Moisture Indicator for Core Dryer – Replace Annually
21999-1124	Core Series Dryer – End Cap
21999-1077-PL	Outer Tube Replacement
21999-0131	Water Separator
21999-0131-Z-FD	Oil Coalescing Filter

Literature –

CORE Dryer Brochure
