UP10 Pivot Series 1″ Metallic Air-Operated Double Diaphragm Pump
Manufacturer: SAMOA
Part #: UP10A-XXX-XXX
Description: The 1” (25 mm) Air Operated Double Diaphragm Pumps made of cast metal can reach a flow rate of up to 200 l/min (52 gal/min) and they offer a wide range of construction materials and porting configurations. The pump design ensures high abrasion resistance when pumping abrasive media and low flow resistance.
Multiple threaded inlet and outlet position options provide maximum installation versatility. Manifolds can rotate 180º to to increase installation possibilities.
With a patented Smooth Start Shifter (3S) actuator and enlarged air passageways, these pumps prevent unexpected stalling and freezing of the Diaphragm Pump. Their modular design simplifies maintenance and makes air valve cartridge replacement fast and easy. The innovative Air Distribution System (ADS) features a frictionless pivot valve design, resulting in maximum air efficiency, minimal wear and significantly reduced pump vibrations and fluid pulsations. Invest in Pivot Series Diaphragm Pumps for an efficient and reliable solution to the most demanding pump applications.
Air operated double diaphragm pumps for dosing, spraying, transferring, evacuating and distributing a wide variety of fluids. SAMOA offers a wide range of material options for chemical compatibility and to withstand abrasion, temperature and fatigue caused by demanding conditions. UP10 Metallic pumps make the difference.
Features:
- HIGHER EFFICIENCY. Maximum fluid flow with reduced air consumption.
- INCREASED RELIABILITY. No stall, no icing, reliable start-up and longer air valve and diaphragm lifes.
- MAXIMUM VERSATILITY. Metal pumps and a wide range of diaphragms, seats and balls offer broad fluid and application compatibility.
- EASY SERVICING. Simplified maintenance and cleaning. Components designed for long life and reliability. This model is a fully groundable ATEX certified pump, for use in potentially explosive atmospheres (Ex II2 GD IIB/IIC 95 ˚C).
Specifications:
| Pump size | 1″ |
| Pressure ratio | 1:1 |
| Maximum free flow delivery | 53 gal/min |
| Air pressure operating range | 20-120 psi |
| Solids in suspension maximum size | 1/4″ |
| Maximum dry suction head | 16 ft |
| Maximum wet suction head | 26 ft |
| Delivery per cycle | 0.2 gal |
| Fluid inlet | 1″ NPT (F) |
| Fluid outlet | 1″ NPT (F) |
| Air inlet | 1/2″ NPSM (F) |
| Air exhaust port | 1″ NPT (F) |
| Sound level | 75 db |
| Certification | ATEX |
| Central body & Air chambers material | Aluminum |
| Fluid ports / Location | 1″ NPT central and lateral threaded |
| Fluid chambers & Manifolds material | Aluminum |
| Hardware Bolts & Inserts material | Carbon steel |
| Diaphragms type & material | (Select option in dropdown) |
| Valve seats material | (Select option in dropdown) |
| Valve balls material | (Select option in dropdown) |
| Weight | 25 lbs |
Parts and Accessories:
| Part No. | Description |
| UP10R-WP-00G | Diaphragm Kit |
| UP10R-WP-0N0 | Ball Kit |
| UP10R-WP-N00 | Seat Kit |
| UP10R-AM-1A0 | Air Valve Module |
| UP10R-AM-200 | Air Sensor Kit |
| UP10R-AM-300 | Air Shaft Kit |
| UP10R-HP-6A0 | Air Piston Kit |
| UP10R-HP-7A0 | Fluid Piston Kit |
| UP10R-HP-1AN | Inlet Manifold |
| UP10R-HP-2AN | Outlet Manifold |
| UP10R-HP-3A0 | Fluid Cover |
| UP10R-HP-5A0 | Central Body |
| UP10R-AM-400 | Air Motor Seals Kit |
| UP10R-HP-8A0 | Central Body Air Cap Kit |
| UP10R-HP-4A0 | Air Cover |
| UP10R-AM-500 | Air Exhaust Kit |
Literature:
- Manual
