Elcometer 456 Straight Ferrous Substrate Thickness Gauge – Scale 6 Probe

Description

Straight Ferrous Substrate Probe | Scale 6 | Elcometer 456

Manufacturer: Elcometer

Part #: T456CF6S

Description: Designed to work with any of our Ferrous or Dual FNF Elcometer 456 Separate Gauges.
Ideal for measuring thick coatings over ferrous metal substrates. Including, but not limited to: pipe wrap, fireproofing, and polyurea.
Specifications:

• Range: F – 0-980 mils (0-25mm) / N – 0-1200 mils (0-30mm)
• Accuracy*: ±1-3% or ±4.0 mil (±100µm)
• Resolution: 1.0 mil: 0-100 mils; 10 mils: 100-1200 mils (10µm: 0-2mm; 100µm: 2-30mm)
• Minimum convex surface radius – 35mm (1.40″)
• Minimum concave surface radius – 170mm (6.70″)
• Minimum headroom – 150mm (5.90″)
• Minimum sample diameter: 51 x 51mm² (2 x 2 sq. inch)

Data Sheet
