Elcometer 456 Right-Angle Dual-Substrate Thickness Probe (Ferrous & Non-Ferrous) – Scale 1

Description

Right Angle Dual Ferrous/Non-Ferrous (FNF) Substrate Probe | Scale 1 | Elcometer 456

Manufacturer: Elcometer

Part #: T456CFNF1R

Description:Designed to work with any of our Elcometer 456 Separate Gauges.
Industrially hardened probe housing designed for taking readings where access is restricted.
Automatic substrate detection.
Specifications:

• Range: 0-60 mils (0-1500µm)
• Accuracy: ±1-3% or ±0.1 mil (±2.5µm)
• Resolution: 0.01 mil: 0-5 mils; 0.1mil: 5-60 mils (0.1µm: 0-100µm; 1µm: 100-1500µm)
• Minimum convex surface radius 10mm (0.39″)
• F Mode: 4mm (0.16″)
• N Mode: 26mm (1.02″)
• Minimum concave surface radius 12.5mm (0.49″)
• Minimum headroom 38mm (1.50″)
• Minimum sample diameter 4mm (0.16″)
• F Mode: 4mm (0.16″)
• N Mode: 6mm (0.24″)
