Elcometer 456 Mini Straight Probe – 0.5 Scale for Non-Ferrous Substrates

Description

Mini Straight Non-Ferrous Substrate Probe | Scale 0.5 | Elcometer 456

Manufacturer: Elcometer

Part #: T456CNM3—A

Description:The all New Elcometer 456 Mini Straight Non-Ferrous Probe is designed to work with our Elcometer 456 Non- Ferrous and Ferrous/Non-Ferrous Separate Gauges.
Ideal for measuring coatings on edges, narrow pipes, wire, or small surface areas.
Specifications:

• Length 45mm
• Range: 0-20 mils (0-500µm)
• Accuracy*: ±1-3% or ±0.1 mil (±2.5µm)
• Resolution: 0.01 mil: 0-5 mils; 0.1 mils: 5-20 mils (0.1µm: 0-100µm; 1µm: 100-500µm)
• Minimum convex surface radius – 6mm (0.24″)
• Minimum concave surface radius – 8.5mm (0.33″)
• Minimum headroom – 6mm (0.24″)
• Minimum sample diameter: 4mm (0.16″)

*Whichever is greater

Data Sheet
